1.5mm SS Coil 304 316 201 HBW Hardness for Building Steel Material
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | TGPX |
| Model Number: | 304 316 304L 316L etc. |
Payment & Shipping Terms:
| Price: | $1,000.00 - $3,000.00/Tons |
|---|---|
| Packaging Details: | Tied up with steel strips and wrapped with water proof paper<br><br>thick plates are packed separately, thin plate are packed in bundles |
| Supply Ability: | 20000 Ton/Tons per Month |
|
Detail Information |
|||
| Standard: | AiSi, ASTM, Bs, DIN, GB, JIS | Width: | 600mm-1250mm, 600mm-1500mm As Required |
|---|---|---|---|
| Length: | Customers' Requirement, 1-12M As Required | Grade: | 201,304,316 Stainless Steel, 200 Series, 300 Series, 400 Series 904,duplex2205/2507 |
| Surface Treatment: | Coated | Tolerance: | ±1% |
| Processing Service: | Bending, Welding, Decoiling, Cutting, Punching | Keyword: | Ss Coil |
| Thickness: | 0.25-3mm As Required | Surface: | No.1,No.4, BA, 2B, 8K, HL Etc. |
| Use: | Metal Roofing Building Steel Material | Delivery Time: | 15 Days |
| MOQ: | 1 Ton | Technique: | Cold Rolled |
| Special Use: | High-strength Steel Plate | Port: | Tianjin Port/Shanghai Port |
| High Light: | 1.5mm Ss Coil 304,201 HBW Ss Coil 304,Building Steel Material ss 316 coils |
||
Product Description
Manufacturer 1.5Mm Thickness 201 304 316 409 Stainless Steel Coil
304
304 stainless steel is a common material in stainless steel with a density of 7.93 g/cm, also known in the industry as 18/8 stainless steel.High temperature resistance 800℃, with the characteristics of good processing performance, high toughness, widely used in the industrial and furniture decoration industry and food and medical industry.
Tensile strength b (MPa)≥515-1035
304 stainless steel atlas
304 stainless steel atlas (6 sheets)
The yield strength is 0.2 (MPa)≥205
Elongation = 5 (%)≥40
Reduction of area bits of p (%)?
Hardness: 201 HBW or less;
92 HRB or less;
210 hv or less
Density (20℃, g/cm) : 7.93
Melting point (℃) : 1398~1454
Specific heat capacity (0~100℃, KJ· kg-1k-1) : 0.50
Thermal conductivity (W·m-1· k-1) :(100℃) 16.3, (500℃) 21.5
Linear expansion coefficient (10-6· k-1) :(0~100℃) 17.2, (0~500℃) 18.4
Resistivity (20 ℃, 10-6 Ω m2 / m) : 0.73
Longitudinal modulus of elasticity (20℃, KN/mm2) : 193
|
Name |
Stainless steel coil |
|
Grade |
201, 304, 316, 316L, 410, 430, etc |
|
Standard |
JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc |
|
Thickness |
0.25 - 3mm |
|
Width range |
600mm - 1500mm |
|
Length |
2000/2438/3048mm/any length as customer requests |
|
Size |
1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, or as required |
|
Finish |
2b, BA, No.4, 8k, hairline, embossed, etched, vibration, pvd color coated, titanium, sand blasted, anti-fingerprint |
|
Color |
Golden, black , sapphire blue, brown, rose gold, bronze, purple, gray, silver, hampagne, violet, blue diamond, etc |
|
Export to |
Korea,Turkey,Kuwait,Malaysia,Vietnam,India,Jordan,etc |
|
Application |
Interior/exterior/architectural/bathroom decoration, elevator decoration, hotel decoration, kitchen equipment, ceiling, cabinet, kitchen sink, advertising nameplate |
|
Lead time |
7 to 25 working days after the receipt of 30% deposit |
|
Payment terms |
30%TT for deposit, 70% balance before shipment or LC at sight |
|
Packing |
Wooden pallet or according to customer's request |
Chemical composition and mechanical properties of stainless steel
|
Grade |
Chemical Composition (%) |
Mechanieal Performece |
|||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Hardness |
|
|
201 |
≤0.15 |
≤1.00 |
5.5/7.5 |
≤0.060 |
≤0.030 |
3.5/5.5 |
16.0/18.0 |
- |
HB≤241,HRB≤100, HV≤240 |
|
304 |
≤0.08 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.03 |
8.0/11.0 |
18.00/20.00 |
- |
HB≤187,HRB≤90,HV≤200 |
|
316 |
≤0.08 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.03 |
10.00/14.00 |
16.0/18.0 |
2.00/3.00 |
HB≤187, HRB≤90 HV≤200 |
|
316L |
≤0.03 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.03 |
10.00/14.00 |
16.0/18.0 |
2.00/3.00 |
HB≤187, HRB≤90 HV≤200 |
|
410 |
≤0.15 |
≤1.00 |
≤1.25 |
≤0.060 |
≤0.030 |
≤0.060 |
11.5/13.5 |
- |
HB≤183, HRB≤88 HV≤200 |
|
430 |
≤0.12 |
≤1.00 |
≤1.25 |
≤0.040 |
≤0.03 |
- |
16.00/18.00 |
- |
HB≤183, HRB≤88 HV≤200 |
Jiangsu Taigang Puxin Stainless Steel Co., Ltd. is a sophisticated manufacturer of steel products. It’s located in Wuxi, which is the biggest base of stainless steel products in China and is also near to Shanghai. We have been devoted in steel industry for nearly 10 years and developed many faithful clients in Europe, South America, Mid-East, India and etc. We have a wide range of stainless steel products. Other metal products are also available if customers require. The annual export volume is about 1000,000 tons. And we promised almost all inquiry will be dealed with within 3 hours. "Punctuality,Integrity, Humanization service” has always been the development principle that strictly adhered by our company and all stuff all the time.
At present, we have five finishing rolling production lines and two hot rolling production lines . Further more advanced automatic width control system (AWC), automatic thickness control system (AGC), bending roll system, work roll channeling roll system and other effective measures are adopted to guarantee product quality. Well-equipped production lines and advanced control systems work together to make sure all the stainless steel products we made are in line with the national standards.
1.Q: Are you trading company or manufacturer ?
A: We are manufactory that specialized in stainless steel products.
2.Q: How long is your delivery time?
A:It takes around 3-5 days for the regular models, and 7 to 10 working days for the special sizes and processing. It is based on the order quantity and requirement..
3.Q: Do you provide samples ? Is it free or extra ?
A:Yes, we would send you small samples for free and need around 4 to 6 days.
4.Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
5.Q: How do you protect the 201 stainless steel sheet surface?
A: We have a high request for our quality, and each plate must have the second layer PVC laser film, one layer is 7C thick, double lays are 14c thick.
6.Q: What is the usage of your products?
A: It is widely used for elevator and kitchen decoration, Luxury door , wall panel and indoor decoration, advertising board, ceiling corridor, hotel hall, storage rack and kinds of entertainment places, etc.
7.Q: Do you have any assurance for your products?
A: It will have the mill test for quality and material report for each shipment.
