Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped

Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped

Product Details:

Place of Origin: Jiangsu, China
Brand Name: TGPX

Payment & Shipping Terms:

Minimum Order Quantity: 1 Ton
Price: $500 - $700/Tons
Packaging Details: Tied up with steel strips and wrapped with water proof paper<br><br>thick plates are packed separately, thin plate are packed in bundles
Supply Ability: 20000 Ton/Tons per Month
Get Best Price Contact Now

Detail Information

Product Name: Astm A53 Zinc Coated Q195 Q235 Q345 Hot Dipped Galvanized Steel Coil Keyword: Galvanized Steel Coil
Shape: Steel Coil Zinc Coating: 30-275g/m2
MOQ: 1 Ton Sample: Avaliable
Packing: Seaworthy Package Grade: SGCC, SGCH, DX51D+Z, Q195, DX53D+Z, SGCC, SGCH,etc.
Delivery Time: Within 15-20days Coil Weight: 3-5 Tons
High Light:

Astm A53 Galvanized Steel Coil

,

Zinc Coated Galvanized Steel Coil

,

Q345 Galvanized Steel Coil

Product Description

Astm A53 Zinc Coated Q195 Q235 Q345 Hot Dipped Galvanized Steel Coil

Specification
Technical Standard
EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653
Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD , S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80
(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm,or customer's requirement
Width
600mm-1500mm,according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)/Electro-Galvanised Steel(EGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C),Oiling(O),Lacquer sealing(L),Phosphating(P),Untreated(U)
Surface Structure
Normal spangle coating(NS),minimized spangle coating(MS),spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm,according to customer's requirement


Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 0Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 1


Our products

Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 3

Company Profile

           Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 5

          Jiangsu Taigang Puxin Stainless Steel Co., Ltd. is a sophisticated manufacturer of steel products. It’s located in Wuxi, which is the biggest base of stainless steel products in China and is also near to Shanghai. We have been devoted in steel industry for nearly 10 years and developed many faithful clients in Europe, South America, Mid-East, India and etc. We have a wide range of stainless steel products.



For galvanized steel coils, the steel sheet is immersed in a molten zinc bath to make a sheet of zinc coated on its surface. It is mainly produced by continuous galvanizing process, that is, the rolled steel plate is continuously immersed in a plating tank with zinc melted to make galvanized steel plate; alloyed galvanized steel plate. This kind of steel plate is also manufactured by hot dip method, but immediately after being out of the tank, it is heated to about 500 ℃ to form an alloy coating of zinc and iron. This galvanized coil has good paint adhesion and weldability.


Galvanized coils can be divided into hot-rolled galvanized coils and cold-rolled hot-dip galvanized coils, which are mainly used in construction, home appliances, automobiles, containers, transportation and household industries. Especially steel structure construction, automobile manufacturing, steel silo manufacturing and other industries. Their main features are: strong corrosion resistance, good surface quality, benefit from deep processing, economical and practical, etc.

Processing Equipmnet

Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 6

Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 7

Packing

Astm A53 Galvanized Steel Coil Zinc Coated Q195 Q235 Q345 Hot Dipped 8

FAQ

1.Q: Are you trading company or manufacturer ?

A: We are manufactory that specialized in stainless steel products.



2.Q: How long is your delivery time?

A:It takes around 3-5 days for the regular models, and 7 to 10 working days for the special sizes and processing. It is based on the order quantity and requirement..



3.Q: Do you provide samples ? Is it free or extra ?

A:Yes, we would send you small samples for free and need around 4 to 6 days.



4.Q: What is your terms of payment ?

A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.



5.Q: How do you protect the 201 stainless steel sheet surface?

A: We have a high request for our quality, and each plate must have the second layer PVC laser film, one layer is 7C thick, double lays are 14c thick.



6.Q: What is the usage of your products?

A: It is widely used for elevator and kitchen decoration, Luxury door , wall panel and indoor decoration, advertising board, ceiling corridor, hotel hall, storage rack and kinds of entertainment places, etc.



7.Q: Do you have any assurance for your products?

A: It will have the mill test for quality and material report for each shipment.
